TBD62308APG,HZ
- Part Number: TBD62308APG,HZ
- Categories:
- Manufacturer: Toshiba Semiconductor and Storage
- MOQ: 1PCS
- In Stock: 10654
- Datasheet:
- Description: IC PWR SWITCH N-CHAN 1:1 16DIP
- Payment method: Paypal/Wire transfer/Visa
- Delivery Method: UPS/DHL/FEDEX/EMS
Reference Price (In US Dollars)
- 1 Pcs$1.432
- 10 Pcs$1.364
- 100 Pcs$1.299
- 1000 Pcs$1.273
- 10000 Pcs$1.273
Quick Request Quote
Payment Methods
Delivery Services
Note: Since the price has fluctuated greatly from last year to the present, the price only for reference. Please submitan inquiry or sent email to
[email protected] let us quote you a best price.
Specifications
Reviews
Packaging
Datasheets
TBD62308APG,HZ Specifications
| Manufacturer | Toshiba Semiconductor and Storage |
| Features | - |
| Interface | On/Off |
| Input Type | Inverting |
| Output Type | N-Channel |
| Switch Type | General Purpose |
| Rds On (Typ) | 370mOhm |
| Mounting Type | Through Hole |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Product Status | Active |
| Voltage - Load | 50V (Max) |
| Fault Protection | - |
| Number of Outputs | 4 |
| Output Configuration | Low Side |
| Ratio - Input:Output | 1:1 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Current - Output (Max) | 1.5A |
| Supplier Device Package | 16-DIP |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
