Manufacturer | STMicroelectronics |
Speed | 72MHz |
RAM Size | 20K x 8 |
Core Size | 32-Bit Single-Core |
EEPROM Size | - |
Peripherals | DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT |
Connectivity | CANbus, I²C, IrDA, LINbus, SPI, UART/USART, USB |
Mounting Type | Surface Mount |
Number of I/O | 37 |
Core Processor | ARM® Cortex®-M3 |
Package / Case | 48-LQFP |
Product Status | Active |
Data Converters | A/D 10x12b |
Oscillator Type | Internal |
Program Memory Size | 64KB (64K x 8) |
Program Memory Type | Flash |
Operating Temperature | -40°C ~ 85°C (TA) |
Supplier Device Package | - |
Voltage - Supply (Vcc/Vdd) | 2V ~ 3.6V |
STM32F103C8T6 Overview
The STM32F103C8T6 medium-density performance line family incorporates the high-performance ARM®Cortex®-M3 32-bit RISC core operating at a 72 MHz frequency, high-speed embedded memories (Flash memory up to 128 Kbytes and SRAM up to 20 Kbytes), and an extensive range of enhanced I/Os and peripherals connected to two APB buses. All devices offer two 12-bit ADCs, three general-purpose 16-bit timers plus one PWM timer, as well as standard and advanced communication interfaces: up to two I2Cs and SPIs, three USARTs, a USB, and a CAN.
Feature
STM32F103C8T6 Applications
Embedded Design & Development, Motor Drive & Control, Medical, Portable Devices, Wireless, Industrial, Imaging, Video & Vision, Consumer Electronics, Automotive
STM32F103C8T6 Pinout
STMicroelectronics is a leading provider of semiconductor solutions for a variety of microelectronics applications and a leading independent semiconductor firm operating globally. The Company is at the forefront of System-on-Chip (SoC) technology, and its solutions play a critical role in supporting current convergence trends thanks to an unmatched mix of silicon and system expertise, manufacturing strength, Intellectual Property (IP) portfolio, and strategic partners.
