PI49FCT3802QEX
- Part Number: PI49FCT3802QEX
- Categories:
- Manufacturer: Diodes Incorporated
- MOQ: 1PCS
- In Stock: N/A
- Datasheet:
- Description: IC CLK BUFFER 1:5 156MHZ 16QSOP
- Payment method: Paypal/Wire transfer/Visa
- Delivery Method: UPS/DHL/FEDEX/EMS
About Products
Due to the shortage of market environment and the price fluctuation, the displayed products can be inquired through RFQ, and we will reply within 24 hours
Quick Request Quote
Payment Methods
Delivery Services
Note: Since the price has fluctuated greatly from last year to the present, the price only for reference. Please submitan inquiry or sent email to
[email protected] let us quote you a best price.
Specifications
Reviews
Packaging
Datasheets
PI49FCT3802QEX Specifications
| Manufacturer | Diodes Incorporated |
| Type | Fanout Buffer (Distribution) |
| Input | CMOS, TTL |
| Output | CMOS, TTL |
| Mounting Type | Surface Mount |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) |
| Product Status | Obsolete |
| Frequency - Max | 156 MHz |
| Voltage - Supply | 3V ~ 3.6V |
| Number of Circuits | 1 |
| Ratio - Input:Output | 1:5 |
| Operating Temperature | 0°C ~ 70°C |
| Supplier Device Package | 16-QSOP |
| Differential - Input:Output | No/No |
