HV20822TQ-G
- Part Number: HV20822TQ-G
- Categories:
- Manufacturer: Microsemi Corporation
- MOQ: 1PCS
- In Stock: 15383
- Datasheet:
- Description: 16-CHANNEL HIGH VOLTAGE ANALOG S
- Payment method: Paypal/Wire transfer/Visa
- Delivery Method: UPS/DHL/FEDEX/EMS
Reference Price (In US Dollars)
- 1 Pcs$24.471
- 10 Pcs$23.305
- 100 Pcs$22.196
- 1000 Pcs$21.76
- 10000 Pcs$21.76
Quick Request Quote
Payment Methods
Delivery Services
Note: Since the price has fluctuated greatly from last year to the present, the price only for reference. Please submitan inquiry or sent email to
[email protected] let us quote you a best price.
Specifications
Reviews
Packaging
HV20822TQ-G Specifications
| Manufacturer | Microsemi Corporation |
| Features | - |
| Applications | Ultrasound |
| Mounting Type | Surface Mount |
| -3db Bandwidth | - |
| Package / Case | 48-TQFP |
| Product Status | Active |
| Switch Circuit | SPST |
| Number of Channels | 16 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Supplier Device Package | 48-TQFP (7x7) |
| On-State Resistance (Max) | 32Ohm |
| Voltage - Supply, Dual (V±) | 4.75V ~ 12.6V |
| Voltage - Supply, Single (V+) | 4.75V ~ 12.6V |
| Multiplexer/Demultiplexer Circuit | 1:1 |
