FAN6520AM
- Part Number: FAN6520AM
- Categories:
- Manufacturer: onsemi
- MOQ: 1PCS
- In Stock: 5000
- Datasheet:
- Description: IC REG CTRLR BUCK 8SOIC
- Payment method: Paypal/Wire transfer/Visa
- Delivery Method: UPS/DHL/FEDEX/EMS
Reference Price (In US Dollars)
- 1 Pcs$0.509
- 10 Pcs$0.484
- 100 Pcs$0.461
- 1000 Pcs$0.452
- 10000 Pcs$0.452
Quick Request Quote
Payment Methods
Delivery Services
Note: Since the price has fluctuated greatly from last year to the present, the price only for reference. Please submitan inquiry or sent email to
[email protected] let us quote you a best price.
Specifications
Reviews
Packaging
Datasheets
FAN6520AM Specifications
| Manufacturer | onsemi |
| Function | Step-Down |
| Topology | Buck |
| Clock Sync | No |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Output Phases | 1 |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Product Status | Obsolete |
| Control Features | Enable |
| Duty Cycle (Max) | 100% |
| Number of Outputs | 1 |
| Serial Interfaces | - |
| Output Configuration | Positive |
| Frequency - Switching | 300kHz |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Synchronous Rectifier | Yes |
| Supplier Device Package | 8-SOIC |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
