DS3991Z+HB
- Part Number: DS3991Z+HB
- Categories:
- Manufacturer: Rochester Electronics, LLC
- MOQ: 1PCS
- In Stock: 8536
- Datasheet:
- Description: IC CCFL CNTRL 80KHZ 16SOIC
- Payment method: Paypal/Wire transfer/Visa
- Delivery Method: UPS/DHL/FEDEX/EMS
Reference Price (In US Dollars)
- 1 Pcs$5.627
- 10 Pcs$5.359
- 100 Pcs$5.104
- 1000 Pcs$5.004
- 10000 Pcs$5.004
Quick Request Quote
Payment Methods
Delivery Services
Note: Since the price has fluctuated greatly from last year to the present, the price only for reference. Please submitan inquiry or sent email to
[email protected] let us quote you a best price.
Specifications
Reviews
Packaging
DS3991Z+HB Specifications
| Manufacturer | Rochester Electronics, LLC |
| Type | CCFL Controller |
| Dimming | Yes |
| Frequency | 40kHz ~ 80kHz |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Product Status | Obsolete |
| Current - Supply | 5 mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 16-SOIC |
| Current - Output Source/Sink | - |
