ADG3308BCBZ-1-RL7
- Part Number: ADG3308BCBZ-1-RL7
- Categories:
- Manufacturer: Analog Devices Inc
- MOQ: 1PCS
- In Stock: 4186
- Datasheet:
- Description: IC TRNSLTR BIDIRECTIONAL 20WLCSP
- Payment method: Paypal/Wire transfer/Visa
- Delivery Method: UPS/DHL/FEDEX/EMS
Reference Price (In US Dollars)
- 1 Pcs$4.196
- 10 Pcs$3.996
- 100 Pcs$3.805
- 1000 Pcs$3.731
- 10000 Pcs$3.731
Quick Request Quote
Payment Methods
Delivery Services
Note: Since the price has fluctuated greatly from last year to the present, the price only for reference. Please submitan inquiry or sent email to
[email protected] let us quote you a best price.
Specifications
Reviews
Packaging
Datasheets
ADG3308BCBZ-1-RL7 Specifications
| Manufacturer | Analog Devices Inc |
| Features | Auto-Direction Sensing |
| Data Rate | 50Mbps |
| Output Type | Tri-State, Non-Inverted |
| Channel Type | Bidirectional |
| Input Signal | - |
| Mounting Type | Surface Mount |
| Output Signal | - |
| Package / Case | 20-UFBGA, WLCSP |
| Product Status | Active |
| Voltage - VCCA | 1.15 V ~ 5.5 V |
| Voltage - VCCB | 1.65 V ~ 5.5 V |
| Translator Type | Voltage Level |
| Number of Circuits | 1 |
| Channels per Circuit | 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Supplier Device Package | 20-WLCSP (2.5x2) |
