74HC85DB,118
- Part Number: 74HC85DB,118
- Categories:
- Manufacturer: Nexperia USA Inc.
- MOQ: 1PCS
- In Stock: 7338
- Datasheet:
- Description: IC COMPARATOR MAGNITUDE 16SSOP
- Payment method: Paypal/Wire transfer/Visa
- Delivery Method: UPS/DHL/FEDEX/EMS
Reference Price (In US Dollars)
- 1 Pcs$0.299
- 10 Pcs$0.285
- 100 Pcs$0.271
- 1000 Pcs$0.266
- 10000 Pcs$0.266
Quick Request Quote
Payment Methods
Delivery Services
Note: Since the price has fluctuated greatly from last year to the present, the price only for reference. Please submitan inquiry or sent email to
[email protected] let us quote you a best price.
Specifications
Reviews
Packaging
Datasheets
74HC85DB,118 Specifications
| Manufacturer | Nexperia USA Inc. |
| Type | Magnitude Comparator |
| Output | Active High |
| Mounting Type | Surface Mount |
| Number of Bits | 4 |
| Package / Case | 16-SSOP (0.209", 5.30mm Width) |
| Product Status | Obsolete |
| Output Function | AB |
| Voltage - Supply | 2V ~ 6V |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | 16-SSOP |
| Current - Quiescent (Iq) | 8 µA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Max Propagation Delay @ V, Max CL | 33ns @ 6V, 50pF |
